| Video Resolution | Up to 4K 60Hz 4:2:0 & 4K30 4:4:4 |
| Vesa Resolution | Up to DCI 4K (4096x2160) |
| HDR Formats/Resolution | 420, 422, 444 (10 and 12 Deep Color), HDR10, HDR10+, HLG |
| Audio Formats Supported HDMI | PCM 2.0 CH, LPCM 5.1 & 7.1, Dolby Digital, DTS 5.1, Dolby Digital Plus, Dolby TrueHD, DTS-HD Master Audio, DTS-X, Dolby Atmos |
| ARC Support | Yes |
| HDBaseT Distance (4K 60 4:2:0) | 40 Meters (131 Feet) (Cat 6a) |
| HDBaseT Distance (Full HD) | 70 Meters (230 Feet) (Cat 6a) |
| HDMI Lead In/Out | Up to 50 Feet (Using Bullet Train HDMI) |
| HDMI Lead In/Out (W/ AOC Cable) | Up to 130 Feet (Using Bullet Train AOC) |
| Bandwidth | 10.2 gbps |
| HDCP 2.2 and earlier |
| HDMI | Type A |
| HDBASET | RJ45 POH for HDBASET Receivers |
| IR | 3.5mm |
| Audio INPUT/OUTPUT (RX/TX) | 3.5mm Stereo / Mini Toslink |
| RS-232 | 3 pin terminal block |
| Power (TX /RX) | 2 pin terminal block |
| Power Consumption (Total) | 9 Watts max |
| Power Supply | Input | AC 100-240V~50/60HZ, Output | DC 48V 2A |
