| Video Resolution | Up to 4K 60Hz 4:4:4 |
| Vesa Resolution | Up to DCI 4K (4096x2160) |
| HDR Formats/Resolution | 420, 422, 444 (10 and 12 Deep Color), HDR10, HDR10+, Dolby Vision (24/30 Frames), HLG |
| Downscaling | 4k (and HDR) down to 1080p |
| Audio Formats Supported HDMI | PCM 2.0 CH, LPCM 5.1 & 7.1, Dolby Digital, DTS 5.1, Dolby Digital Plus, Dolby TrueHD, DTS-HD Master Audio, DTS-X, Dolby Atmos |
| Audio Formats Supported Extracted (Toslink Tx Only) | PCM 2.0 Ch, LPCM 5.1 & 7.1, Dolby Digital, DTS 5.1, Dolby Digital Plus, Dolby TrueHD, DTS-HD Master Audio |
| HDBaseT (CAT) Distance (4K) | 40M (131 Feet) |
| HDBaseT (CAT) Distance (Full HD) | 70M (230 Feet) |
| HDMI Lead In/Out (up to 4K60 4:4:4) | Up to 50 Feet (Bullet Train HDMI) |
| HDMI Lead In/Out (w/ AOC Cable) (up to 4K60 4:4:4) | Up to 130 Feet (w/ Bullet Train AOC) |
| Bandwidth | 18 gbps (w/ITC) |
| HDCP 2.2 and earlier |
| HDMI (TX&RX) | Type A |
| HDBaseT | RJ45 w/ PoH for HDbaseT Receivers |
| Audio (Extracted Digital) | Toslink |
| Audio (Extracted Analog) | 5 pin terminal block (balanced) |
| IR | Rx3.5mm Stereo (3 Conductor) |
| RS232 | 3 pin terminal block |
| Power Consumption | 38 Watts max |
| Power Supply | Input | AC 100-240V~50/60HZ, Output | DC 12V 4A |
