| Video Codec | Proprietary codec based on M-JPEG |
| Audio Codec | Proprietary codec |
| Latency | 16ms@60Hz |
| Streaming Protocols | TCP, UDP, IP, IGMP-V2 |
| Copy Protection | HDCP 2.2 and earlier |
| Signal Type | DVI 1.0, HDMI 2.0b |
| Video Resolution | 720p@50/60Hz; 1080p@24, 50 & 60Hz; 4K@50/60Hz 4:4:4; 4K@30Hz 4:4:4; 4K@60Hz 4:2:0; 4:2:2 4K @24Hz 4:2:0/4:2:2 (ultrawide support) |
| Chroma Subsampling | 4:4:4, 4:2:2, 4:2:0, RGB |
| Bit Depth per Color | 1080p 8-, 10-, 12-bit, 4K 8-, 10-, 12-bit |
| Visually Lossless | 4096x2160p@60Hz (8-bit) 4:4:4 or RGB; 3840x2160p@60Hz (12-bit) 4:2:2 Dolby Vision; 3840x2160p@60Hz (10-bit) 4:2:2 HDR10/HLG; 1920x1080p@60Hz (12-bit) |
| Audio Format (end to end) | PCM 2, 5.1, 7.1 channel, Dolby Digital 5.1 channel, Dolby Digital Plus, DTS 5.1 channel, DTS-ES, DTS-HD high resolution, DTS-HD master audio, Dolby Atmos, DTS:X |
| Audio Format (HDMI Loopout) | Same as end-to-end |
| Embedded Audio | Stereo Analog Audio (3.5mm jack) |
| De-embedded Audio | Balanced Stereo Analog Audio (5-pin phoenix only, downmixed to 2ch) |
| Ethernet | (1) x female RJ45, PoE |
| SFP | (1) x SFP Slot |
| HDMI | (2) x HDMI Type A 19-pin, female, one HDMI input, one HDMI loop out |
| Audio | (1) x 5-pin terminal block, balanced L/R audio out (downmixed to 2ch audio) / (1) x Toslink audio out (future audio return support only) / (1) x 3.5mm mini jack, Audio in |
| IR | (3) x 3.5mm mini-stereo jack, one IR-Pass, one IR-EYE, one IR-out |
| RS232 | (1) x 3-pin terminal block |
| USB | (1) x USB 2.0 Type-B for USB extension and KVM / (1) x USB Type-C for MXnet service |
| Ethernet Distance | 100 meters / 330 feet over Cat5e and above |
| SFP and Fiber Distance | 1000BASE-SX SFP transceiver module (MMF, 850nm, 550m, LC, DOM) / 1000BASE-LX/LH SFP 1310nm 10km transceiver module |
| Acoustic Noise Level | 0dB |
| Max. Power Consumption | 10.3W |
| PoE | IEEE 802.3af (15.4W) |
| Power Supply Unit | Input | AC 120-240V-50/60Hz 0.8A |
| Mounting | Rack and furniture mount support |
