| Single Gang |
| Compatible Box Types | Mud Rings, Stud Mount, Clamp Mount, Metal & Plastic Boxes, LV Boxes |
| Video Resolutions | Up to 4K 60Hz 4:2:0 & 4K30 4:4:4 |
| Vesa Resolutions | Up to 2560x2048 (QSXGA) |
| HDR Formats/Resolutions | 4K24 4:2:2 12 bit, 4K24 4:2:0 10 bit |
| Color Space | YUV (Component), RGB (CSC | REC. 601, REC. 709, BT2020, DCI, P3 D6500 |
| Audio Formats Supported HDMI | PCM 2.0 CH, LPCM 5.1 & 7.1, Dolby Digital, DTS 5.1, Dolby Digital Plus, Dolby TrueHD, DTS-HD Master Audio, DTS-X, Dolby Atmos |
| Distance 1080p | 100M (330 Feet) |
| Distance 4K & HDR | 70M (250 Feet)(With CAT6A/7) |
| Compatible Receivers | AC-EX100-UHD-R3 (100M), AC-EX70-UHD-R (70M) |
| Bandwidth | 10.2 Gbps |
| HDMI (Input) | Type A |
| USB-C Port (Input) | USB-C |
| HDBaseT (Output to receiver) | RJ45 |
