| Signal Type | DVI 1.0, HDMI 2.0b |
| Video Resolution | 4K@60Hz 4:4:4, 4K@30Hz 4:4:4, 4K@60Hz, 4:2:0 |
| HDR Format | HDR 10, HLG, DV |
| Chroma Subsampling | 444, 422, 420 |
| Bit Depth per Color | 1080P (16Bit), 4k (10, 12 Bit) |
| Audio Format | PCM 2, 5.1, 7.1 Channel, Dolby Digital 5.1 Channel, Dolby Digital Plus, DTS 5.1 Channel, DTS–ES, DTS–HD High Resolution |
| Embedded Audio | Stereo Analog Audio |
| De-Embedded Audio | Balanced Analog Audio |
| Ethernet | (1) × female RJ-45, PoE |
| SFP | (1) × SFP Slot |
| HDMI | (2) × HDMI Type A 19-pin, female, one HDMI input, one HDMI loop out |
| Audio | (1) × 5 Pin Terminal Block, Balanced L/R Audio out, (1) × 3.5 mm mini stereo jack, Audio in |
| IR | (3) × 3.5mm mini-stereo jack, one IR-Pass, one IR-EYE, one IR-out |
| RS232 | (1) × 5 Pin Terminal Block |
| USB | (1) × USB 2.0 Type-B for USB extension and KVM, (1) × USB Micro Type-B for MXNET servicepre;"> |
| Max Power Consumption | 6.5W |
| PoE (Power over Ethernet) | IEEE 802.3af (15.4W) |
| Power Supply Unit | Input | AC 120-240V-50/60Hz 0.8A, Output | DC 12V 2A |
