| Video Resolutions | Up to 8K 60Hz 4:2:0/8K 30Hz 4:4:4/4K 120 Hz |
| HDR Formats/Resolutions | 420, 422, 444 (10 and 12 deep color) HDR10, HDR10+, Dolby Vision, HLG |
| Color Space | YUV (Component), RGB (CSC | REC. 601, REC. 709, BT2020, DCI, P3 D6500) |
| Chroma Subsampling | 4:4:4, 4:2:2, 4:2:0 Supported |
| Deep Color | Up to 16 Bit (1080p) up to 12 Bit (4K) |
| Scaling (Resolution, Output 2 Only) | 8K to 4K or 8K to 2K (1080p) |
| Audio Formats Supported HDMI | PCM 2.0 CH, LPCM 5.1 and 7.1, Dolby Digital, DTS 5.1, Dolby Digital Plus, Dolby TrueHD, DTS-HD Master Audio, DTS-X, Dolby Atmos |
| Audio Formats Supported Extracted (Digital Toslink) | LPCM up to 5.1 96KHz 24 Bit, Dolby Digital 5.1, DTS Hires Audio |
| Audio Formats Supported Extracted (2 CH Port) | PCM 2 CH |
| HDMI In/Out (48G BPS) | Up to 4 meters (Using bullet train 48G BPS HDMI) |
| HDMI In/Out (W/AOC Cable) (48G BPS) | Up to 100 meters (Using bullet train 48G BPS AOC) |
| Bandwidth | 40 GBPS (FRL 5) |
| HDCP | HDCP 2.3 and earlier |
| HDMI | Type A |
| Audio (Extracted Analog) | 3.5 mm |
| Audio (Extracted Digital) | Optical Toslink-Mini toslink adaptor included |
| Firmware/Control | USB-C and RS232 (3 Pin Terminal Block) |
| Power | USB-C |
| Power Consumption (total) | 2.5 watts max |
| Power Supply | Input-AC 100-240V~50/60 Hz / Output | DC 5V 1A |
