| Video Resolutions | Up to 8k 60Hz 4:2:0/8K 30Hz 4:4:4/4k 120 |
| SMPTE/CTA/DCI Resolutions | Up to 4K120Hz 4:4:4/8K60Hz 4:2:0 |
| VESA Resolutions | Up to DCI 4k (4096x2160) |
| HDR Formats | HDR10, HDR10+, HLG, DV, Dynamic HDR |
| Chroma Supported | 4:2:0, 4:2:2, 4:4:4 |
| Color Space | YUV (Component), RGB (CSC | Rec. 601, Rec. 709, BT2020, DCI, P3 D6500) |
| Deep Color | Up to 16 bit (1080p), up to 12 BIT (4k), up to 10 BIT (8k) |
| HDMI Bitstream | LPCM up to 7.1 192 KHz 24Bit, Dolby Digital, Dolby Digital Plus, Dolby MAT, Dolby TrueHD, Dolby Atmos (All Formats), Dolby AC-4, DTS Digital, DTS Discrete, DTS Express, DTS HiRes Audio, DTS Master Audio, DTS:X |
| Extracted Audio (SPDIF TOSLINK) | LPCM up to 5.1 96KHz 24 Bit, Dolby Digital 5.1, DTS HiRes Audio |
| Extracted Audio (Stereo RCA) | PCM 2 CH |
| Extracted Audio Modes | Bind to Output |
| Bandwidth | 40Gbps (FRL 5) |
| HDCP | 1.4, 2.X Support HDMI | Type A |
| LAN | RJ45 w/ Web Interface/ Control |
| Audio (Extracted Digital) | Toslink |
| Audio (Extracted Analog) | L/R Audio |
| IR RX | Window Only (Remote Included) |
| RS232 | 3 Pin Terminal Block |
| Power Consumption (Total) | 7 Watts Max |
