| Video Resolutions | Up to 4K60 |
| HDR Formats/Resolutions | 420, 422, 444 (10 and 12 deep color) HDR10, HDR10+, Dolby Vision, HLG |
| Color Space | YUV (Component), RGB (CSC | Rec. 601, Rec. 709, BT2020, DCI, P3 D6500) |
| Chroma Subsampling | 4:4:4, 4:2:2, 4:2:0 Supported |
| Deep Color | Up to 16 bit |
| Audio Formats Supported HDMI | PCM 2.0 Ch, LPCM 5.1 and 7.1, Dolby Digital, DTS 5.1, Dolby Digital Plus, Dolby TrueHD, DTS-HD Master Audio, DTS-X, Dolby Atmos |
| Analog Input Voltage | 0.8 VRMS; 2.3 Vp-p |
| Audio Formats Supported Extracted (2CH Port) | PCM 2 CH |
| Analog Output Peak Voltage | 1.39 VRMS; 3.94 Vp-p |
| HDMI In/Out (4k60 4:4:4) | Up to 50 feet (using bullet train HDMI) |
| HDMI In/Out (w/ AOC Cable) (4k60 4:4:4) | Up to 130 feet (using bullet train AOC) |
| Bandwidth | 18 Gbps (TMDS) |
| HDCP | HDCP 2.3 and earlier |
| Control | Lan, RS232 |
| Drivers | C4, RTI, ELAN, URC |
| AVPro WebUI | Yes |
| HDMI | Type A |
| LAN | RJ45 with Web interface / Control |
| Audio (Analog Input) | RCA |
| Audio (Extracted Analog) | 5 Pin Terminal Block |
| RS232 | 3 Pin Terminal Block |
| Power Consumption (Total) | 23.04W (12V 1.92A) |
| Power Supply | Input-AC 100-240V~50/60Hz / Output-DC 12V 5A |
