| Video Resolution | Up to 4K 60Hz 4:4:4 |
| Vesa Resolution | Up to DCI 4K (4096x2160) |
| HDR resolutions | 420, 422, 444 (10 and 12 Deep Color) HDR10, HDR10+, HLG, Dolby Vision |
| Audio Formats Supported HDMI | PCM 2.0 CH, LPCM 5.1 & 7.1, Dolby Digital, DTS 5.1, Dolby Digital Plus, Dolby TrueHD, DTS-HD Master Audio, DTS-X, Dolby Atmos |
| Audio Formats Supported Extracted | Transmitter (Toslink Out) | PCM 2.0 Ch, LPCM 5.1 & 7.1, Dolby Digital, DTS 5.1, Dolby Digital Plus (No Downmixing) - Extract Local or ARC |
| Audio Formats Supported | Receiver (Toslink Input) | PCM 2.0 Ch, LPCM 5.1 & 7.1, Dolby Digital, DTS 5.1, Dolby Digital Plus (No Downmixing) - Input for ARC |
| ARC (Audio Return Channel) | Via Toslink or HDMI |
| Fiber Type | Multimode (OM3 Recommended) or Singlemode |
| Connector | LC (Lucent) |
| Recommended Fiber | Cleerline SSF |
| SFP (Small Form-factor Pluggable Transceiver) | Universal and changeable - 300m/2km built in |
| OM3 Multi-mode (Full 4K) | 300M (1000 Feet) |
| Single-mode (Full 4K) | 2KM (1.25 Miles) |
| HDMI Lead In/Out (up to 4K60 4:4:4) | Up to 50 Feet (Bullet Train HDMI) |
| HDMI Lead In/Out (w/ AOC Cable) (up to 4K60 4:4:4) | Up to 130 Feet (w/ Bullet Train AOC) |
| Bandwidth | 18Gbps |
| HDCP 2.2 and Earlier |
| HDMI (TX & RX) | Type A |
| Audio (Extracted/Embedded) (TX & RX) | Toslink |
| IR Tx (TX & RX) | 3.5mm Mono (2 Conductor) |
| IR Rx (TX & RX) | 3.5mm Stereo (3 Conductor) |
| RS-232 (TX & RX) | 3 pin terminal block |
| Power (TX & RX) | 2 pin terminal block |
| Power Consumption | 9 Watts max pair |
| Power Supply | Input | AC 100-240V~50/60HZ, Output | DC 48V .5A (Wall Version) |
