| Video Resolutions | Up to 8K 60Hz 4:2:0/8K 30 Hz 4:4:4/4K 120Hz |
| HDR Formats/Resolutions | 4:2:0, 4:2:2, 4:4:4 (10-and 12-Bit deep color) HDR10, HDR10+, Dolby Vision, HLG |
| Color Space | YUV (Component), RGB (CSC | REC, 601, REC. 709, BT. 2020, DCI-P3 D65) |
| Chroma Subsampling | 4:4:4, 4:2:2, and 4:2:0 Supported |
| Deep Color | Up to 16 Bit (1080p), Up to 12 Bit (4K), Up to 10-Bit (8K) |
| Resolution Scaling (Available on all outputs) | 8K to 4K or 8K/4K to 1080p |
| Additional HDMI 2.1 Features | ALLM, VRR, QMS, QFT, HFR |
| HDMI Bitstream | LPCM up to 7.1, 192 KHz 24-Bit, Dolby Digital, Dolby Digital Plus, Dolby TrueHD, Dolby Atmos (All formats), Dolby AC-4, DTS-Digital Surround, DTS-ES Discrete, DTS-HD High Res Audio, DTS-HD Master Audio, DTS:X |
| Extracted Audio (SPDIF TOSLINK) | LPCM up to 5.1, 96 KHz 24-Bit, Dolby Digital 5.1, DTS-HD High Res Audio |
| Extracted Audio (Stereo RCA) | PCM 2 CH |
| Extracted Audio Modes | Bind to Input, Bind to Output or Matrix (independent) |
| Audio Delay (Per Output, Extracted) | Up to 630ms |
| Passive HDMI In/Out | Up to 32.8 FT |
| AOC HDMI In/Out | 328 FT |
| Bandwidth | 40GBPS (FRL 5) |
| Ports | LAN, RS232, IR Window |
| Drivers | C4, RTI, ELAN, Crestron, URC |
| HDMI | Type A |
| LAN | RJ45 W/Web Interface/Control |
| Audio (Extracted Digital) | Toslink |
| Audio (Extracted Analog) | L/R Audio |
| IR RX | Window Only (Remote Included) |
| RS232 | 3 Pin Terminal Block |
| Power Consumption (total) | 90 watts max |
| Power Supply-matrix | Input-AC 100-240V~50/60Hz / Output-DC 48V 3.75A |
