| HDMI Inputs | 8 |
| HDMI Outputs | 8 |
| HDMI Output Format | 2.0 (a/b) |
| Video Formats Supported | 4K60 (all up to 4:4:4), 4K30, 1080P, 1080I, 720P, 576P, 480P, 576I, 480I |
| Video Scaling Modes (per output): Bypass, HDBT Compatibility (9G), 4K->2K, 2K->4K |
| HDCP Versions | 2.2 and earlier |
| Signal Rate | 18 Gbps |
| HDR Supported | HDR 10, Dolby Vision |
| Audio formats supported (HDMI) | Up to DTS-HD, Dolby TrueHD |
| SPDIF Audio Outputs | 8 |
| Audio Formats Supported (SPDIF) | Up to Dolby 7.1, DTS, & LPCM |
| Balanced Audio Outputs | 8 |
| Balanced Audio Output Level | Line |
| Audio Delay (per output balanced/SPDIF) | Up to 630MS |
| EDID Management | SDR & HDR Presets up to 18Gbps (4K 4:4:4), Custom EDIDs, EDID Copy/Emulate |
