| Video Resolutions | Up to 4K 60Hz 4:4:4 |
| VESA Resolutions | Up to DCI 4K (4096 x 2160) 5K (Up to 5120 x 3200) |
| HDR Formats/Resolutions | 420, 422, 444, (10 and 12 deep color) HDR10, HDR10+, Dolby Vision, HLG |
| Color Space | YUV (Component), RGB (CSC | REC. 601, REC. 709, BT2020, DCI, P3 D6500) |
| Chroma Subsampling | 4:4:4, 4:2:2, 4:2:0 Supported |
| Deep Color | Up to 16 Bit (1080), Up to 12 Bit (4K) |
| Audio Formats Supported HDMI | PCM 2.0 CH, LPCM 5.1 and 7.1, Dolby Digital, DTS 5.1, Dolby Digital Plus, Dolby TrueHD, DTS-HD Master Audio, DTS-X, Dolby Atmos |
| Audio Formats Supported Extracted (Toslink) | PCM 2.0 CH, LPCM 6 CH, LPCM 7 CH, Dolby Digital, Dolby Digital Plus, DTS-Master Audio |
| Audio Formats Supported Extracted (2 CH Port) | PCM 2 CH |
| Audio Extraction Location | Follows Output (Selectable) |
| HDMI In/Out (4K60 4:4:4) | Up to 50 FT |
| HDMI In/Out (W/ AOC Cable) (4K60 4:4:4) | Up to 130 FT |
| Bandwidth | 18 GBPS |
| HDCP | HDCP 2.2 and Earlier |
| Ports | LAN, RS232, IR Window |
| Drivers | C4, RTI, ELAN, Crestron, URC |
| LAN Web OS | Yes |
| HDMI | Type A |
| LAN | RJ45 W/Web Interface/Control |
| Audio (Extracted Digital) | Toslink |
| Audio (Extracted Analog) | L/R Audio |
| IR RX | Window Only (Remote Included) |
| RS232 | 3 Pin Terminal Block |
| Power Consumption (total) | 12 watts max |
| Power Supply-Matrix | Input-AC 100-240V~50/60 Hz / Output-DC 12V 2A |
