| Video Resolutions | Up to 4k 60HZ 4:4:4 |
| VESA Resolutions | Up to DCI 4k (4096x2160) 5k (Up to 5120x3200) |
| HDR Formats/Resolutions | 420, 422, 444 (10 and 12 Deep Color) HDR10, HDR10+, Dolby Vision, HLG |
| Color Space | YUV (Component), RGB (CSC | Rec. 601, Rec. 709, BT2020, DCI, P3 D6500) |
| Chroma Subsampling | 4:4:4, 4:2:2, 4:2:0 Supported |
| Deep Color | Up to 16 bit (1080), up to 12 BIT (4k) |
| Audio Formats Supported HDMI | PCM 2.0 Ch, LPCM 5.1 & 7.1, Dolby Digital, DTS 5.1, Dolby Digital Plus, Dolby TrueHD, DTS-HD Master Audio, DTS-X, Dolby Atmos |
| Audio Formats Supported Extracted (TOSLINK) | PCM 2.0 Ch, LPCM 6 CH, LPCM 7 CH, Dolby Digital, Dolby Digital Plus, DTS- Master Audio |
| Audio Formats Supported Extracted (2CH Port) | PCM 2 CH |
| Audio Extraction Location | Bind to INPUT, Bind to OUTPUT, or Matrix (Independent) |
| Audio Delay (Per OUTPUT, Extracted) | Up To 630ms |
| HDMI IN/OUT (4K60 4:4:4) | Up to 50 Feet (Using Bullet Train HDMI) |
| HDMI IN/OUT (W/ AOC Cable) (4k60 4:4:4) | Up to 130 Feet (Using Bullet Train AOC) |
| Bandwidth | 18 GBPS |
| Drivers | C4, RTI, ELAN, CRESTRON, URC |
| HDMI | Type A |
| LAN | RJ45 w/ Web Interface/ Control |
| Audio (Extracted Digital) | Toslink |
| Audio (Extracted Analog) | 5 PIN Terminal Block (Balanced) |
| IR RX | 3.5MM Stereo (3 Conductor) |
| RS232 | 3 Pin Terminal Block |
