| Video Resolutions | Up to 4k 60HZ 4:4:4 |
| VESA Resolutions | Up to DCI 4k (4096x2160) |
| HDR Formats/Resolutions | 420, 422, 444 (10 and 12 Deep Color) HDR10, HDR10+, Dolby Vision, HLG Color Space YUV (Component), RGB (CSC | Rec. 601, Rec. 709, BT2020, DCI, P3 D6500) |
| Chroma Subsampling | 4:4:4, 4:2:2, 4:2:0 Supported |
| Deep Color | Up to 16 bit (1080), up to 12 BIT (4k) |
| Scalers (HDMI) Per Output Optional | 1080P to 4k Up-Scaling (Resolutions Only, Framerate Stays the same) |
| Scalers (HDBaseT) Per Output Optional | 4k to 1080P Down-Scaling (Resolutions Only, Framerate Stays the same) |
| Audio Formats Supported HDMI | PCM 2.0 Ch, LPCM 5.1 & 7.1, Dolby Digtal, DTS 5.1, Dolby Digital Plus, Dolby TrueHD, DTS-HD Master Audio, DTS-X, Dolby Atmos |
| Audio Formats Supported Extracted (TOSLINK) | Always down-mixed to 2ch. |
| Audio Formats Supported Extracted (2CH Port) | Always down-mixed to 2ch. |
| Audio Extraction Location | Bind to INPUT, Bind to OUTPUT, or Matrix (Independent) |
| Audio Delay (Per Output, Extracted) | Up To 630ms Bandwidth HDMI | 18 GBPS Uncompressed |
| Bandwidth HDBaseT | 18 GBPS (Uses ICT Above 10.2 GBPS Signals) |
| HDCP | HDCP 2.3 and Earlier |
| POH For Receivers (No need to power receivers) | Yes, All Outputs |
| Ports | LAN, RS232, IR |
| Drivers | C4, RTI, ELAN, CRESTRON, URC |
| HDMI | Type A |
| HDBaseT | RJ45 W/ POH for HDBaseT Receivers |
| LAN | RJ45 w/ Web Interface/ Control |
| Audio (Extracted Digital) | Toslink |
| Audio (Extracted Analog) | 5 PIN Terminal Block (Balanced) |
| IR | 3.5MM Stereo (3 Conductor) |
| RS232 | 3 Pin Terminal Block |
