| Video Resolutions |
Up to 4K 60Hz 4:4:4 |
| VESA Resolutions Up |
to DCI 4K (4096x2160) |
| HDR Formats/Resolutions |
420, 422, 444 (10 and 12 Deep Color) HDR10, HDR10+, Dolby Vision (24/30 Frames), HLG |
| Color Space |
YUV (Component), RGB (CSC |
Rec. 601, Rec. 709, BT2020, DCI, P3 D6500) |
| Chroma Subsampling |
4:4:4, 4:2:2, 4:2:0 Supported |
| Deep Color |
Up to 16 bit (1080), Up to 12 bit (4K) |
| Scalers (HDMI) Per Output Optional |
1080P to 4K (Resolution Only, Framerate stays the same) |
| Scalers (HDBaseT) Per Output Optional |
4K to 1080P (Resolution Only, Framerate stays the same) |
| Audio Formats Supported HDMI |
PCM 2.0 Ch, LPCM 5.1 & 7.1, Dolby Digital, DTS 5.1, Dolby Digital Plus, Dolby TrueHD, DTS-HD Master Audio, DTS-X, Dolby Atmos |
| Audio Formats Supported Extracted (Toslink) |
PCM 2 Ch, LPCM 6 Ch, LPCM 7 Ch, Dolby Digital, Dolby Digital Plus, DTS-HD Master Audio |
| Audio Formats Supported Extracted (2CH Port) |
PCM 2 CH (No Downmix) |
| Audio Extraction Location |
Bind to Input, Bind to Output or Matrix (Independent) |
| Audio Delay (Per Output, Extracted) |
Up to 630MS |
| HDBaseT Out (4K60 4:4:4 & HDR) w/ AC-EX70-444-RNE |
70 Meters / 230 Feet (Cat 6a) |
| HDBaseT Out (1080P) w/ AC-EX70-444-RNE |
100 Meters / 330 Feet (Cat 6a) |
| HDBaseT Out (4K60 4:2:0 Max) w/ AC-EX70-UHD-R |
40 Meters / 131 Feet (Cat 6a) |
| HDBaseT Out (1080P) w/ AC-EX70-UHD-R |
70 Meters / 230 Feet (Cat 6a) |
| HDMI In/Out (4K60 4:4:4) |
Up to 50 Feet (using Bullet Train HDMI) |
| HDMI In/Out (w/ AOC Cable) (4K60 4:4:4) |
Up to 130 Feet (using Bullet Train AOC) |
| Bandwidth HDMI |
18 Gbps Uncompressed |
| Bandwidth HDBaseT |
18 Gbps (Uses ICT above 10.2 Gbps signals) |
| Ports |
LAN, RS232, IR, Mini USB |
| Drivers |
C4, RTI, ELAN, Crestron, URC |
| HDMI |
Type A |
| HDBaseT |
RJ45 w/ PoH for HDbaseT Receivers |
| LAN |
RJ45 w/ Web Interface/Control |
| Audio (Extracted Digital) |
Toslink |
| Audio (Extracted Analog) |
5 pin terminal block (balanced) |
| IR Rx |
3.5mm Stereo (3 Conductor) |
| RS-232 |
3 pin terminal block |
