| Video Resolution | Up to 4K 60hz 4:4:4 |
| Vesa Resolution | Up to DCI 4K (4096 x 2160) 5K (up to 5120 x 3200) |
| HDR Formats/Resolution | 420, 422, 444 (10 and 12 deep color), HDR10, HDR10+, Dolby Vision, HLG |
| Audio Formats Supported HDMI | PCM 2.0 CH, LPCM 5.1 & 7.1, Dolby Digital, DTS 5.1, Dolby Digital Plus, Dolby TrueHD, DTS-HD Master Audio, DTS-X, Dolby Atmos |
| Distance HDMI In/Out (4K60 4:4:4) | Up to 50 feet (using Bullet Train HDMI) |
| Distance HDMI In/Out (w/ AOC Cable) (4K60 4:4:4) | Up to 130 feet (using Bullet Train AOC) |
| Bandwidth | 18 GBPS |
| HDCP 2.2 and earlier |
| HDMI (Input) | Type A |
| LAN | RJ45 W/ Web Interface/Control |
| Firmware | Mini USB |
| Power Consumption (total) | 12 watts max |
| Power Supply | Input | AC 100-240V~50/60HZ, Output | DC 12V 2A |
