| Video Resolutions | Up to 4K 60Hz 4:4:4 |
| VESA Resolutions | Up to DCI 4K (4096 x 2160) |
| HDR Formats/Resolutions | 420, 422, 444 (10 and 12 Deep Color) HDR10, HDR10+, Dolby Vision (24/30 Frames), HLG |
| Color Space | YUV (Component), RGB (CSC | REC. 601, REC. 709, BT2020, DCI, P3 D6500) |
| Chroma Subsampling | 4:4:4, 4:2:2, 4:2:0 Supported |
| Deep Color | Up to 16 Bit (1080), Up to 12 Bit (4K) |
| Audio Formats Supported HDMI | PCM 2.0 CH, LPCM 5.1 and 7.1, Dolby Digital, DTS 5.1, Dolby Digital Plus, Dolby TrueHD, DTS-HD Master Audio, DTS-X, Dolby Atmos |
| Audio Formats Supported Extracted (COAX) | PCM 2 CH |
| Audio Extraction Location | Bind to Input, Bind to Output or Matrix (Independent) |
| HDMI In/Out (4K60 4:4:4) | Up to 50 FT |
| HDMI In/Out (with AOC Cable) (4K60 4:4:4) | Up to 130 FT |
| Bandwidth | 18 GBPS |
| HDCP | HDCP 2.2 and Earlier |
| Ports | LAN, RS232, IR, MICR USB |
| Drivers | C4, RTI, ELAN, CRESTRON, URC |
| PC Software | Yes |
| LAN Web OS | Yes |
| HDMI | Type A |
| LAN | RJ45 with Web Interface/Control |
| Audio (Extracted Analog) | 5 Pin Terminal Block |
| IR RX | 3.5mm Stereo (3 Conductor) |
| RS232 | 3 Pin Terminal Block |
| USB | Micro-For UART Communication/Control |
| Power Consumption (Total) | 92 watts max |
| Power Supply-Matrix | Input-AC 100-240V~50/60 Hz / Output-DC 48V 3A |
