| Ethernet | (48) x SFP+ Ports-10GBE/1GBE, 10GBE by Default / (6) x QSFP+ Ports-40GBE by default, support 1x QSFP+ to 4x 10G SFP+ split / (1) 10/100/1000 Base-T Management Port (MGMT) |
| RS232 | (1) x RJ45 Console Port (out-of-band) |
| USB | (1) x USB 2.0 Type-A for MXNet service and storage |
| Ethernet Distance | 330 FT over CAT5E |
| SFP+ and Fiber Distance | 10G SFP+ DAC Cable up to 1 meters, 10G SFP+ AOC Cable up to 3 meters, 10G SFP+ multimode transceiver over multimode fiber up to 550 meters 10G SFP+ single mode transceiver over single mode fiber up to 20 kilometers |
| LED Indicators Usages | (6) x groups of LED indicators indicate QSFP+ to four 10G SFP+ split |
| LED Indicators | (24) |
| Broadcom Switch Chip | BCM56864 |
| CPU | Intel Atom® Processor C2538, 2M Cache, 2.40 GHZ, 4 Cores |
| Memory | DDR3 8GB |
| Storage | MSATA SSD 16GB |
| Five System LED Indicators | Two fans indicators and three for system |
| Reset Button | (1) |
| Max SDVOE Endpoints | 72 |
| Switching Capacity | 1440 GBPS |
| Throughput | 1071 MPPS |
| MAC Address | 96K |
| Routing Table | 8K |
| ARP Table | 208K |
| Max Power Consumption | 400W |
| Power Supply Unit | Power Input AC-100~240V, 50~60Hz / Default with two redundant hot-swappable AC power supply |
| System Fans | 1+4 Redundant hot-swappable fan modules, front-to-back airflow |
| Thermal Dissipation | 1,367.68 BTU/HR |
