| Ethernet (24) x SFP+ Ports -10GBE/1GBE, 10GBE by default / (2) x QSFP+ Ports-40GBE by default, Support 1 x QSFP+ to 4 x 10G SFP+ Split / (1) 10/100/1000Base-T Management Port (MGMT) |
| RS232 | (1) x RJ45 Console Port (Out-of-Band) |
| USB | (1) x USB 2.0 Type-A for MXNet Service and Storage |
| Ethernet Distance | 330 FT over CAT5E |
| SFP+ and Fiber Distance | 10G SFP+ DAC Cable up to 1 meters, 10G SFP+ AOC Cable up to 3 meters, 10G SFP+ Multimode transceiver over multimode fiber up to 550 meters 10G SFP+ single mode transceiver over single mode fiber up to 20 kilometers |
| Max SDVOE Endpoints | 32 |
| Switching Capacity | 640 GBPS |
| Forwarding Rate | 480 MPPS |
| MAC Address | 32K |
| Jumbo Frame | 12K |
| ACL Table | 3K (ingress) + 1K (egress) |
| Queues per Port | 8 |
| Vlan Table | 4K |
| Max Power Consumption | 70W |
| Thermal Dissipation | 239.34 BTU/HR |
| Power Supply Unit | AC-100~240VAC, 50~60Hz / DC-Input 36V-72V / Default with two power supply units, one DC and one AC |
