| Ethernet | (1) 10G female RJ45 port for SDVoE and Dante streams transmissions, (1) 1G female RJ45 port for Ethernet extension or CBOX control, Both are PoE compatible |
| SFP+ | (1) 10G SFP+ Port used for SDVoE and Dante streams transmissions |
| HDMI | (1) HDMI input (1) HDMI output |
| Audio | (1) TOSLINK (1) x 3 Pin Terminal Block (1) 3.5mm female stereo jack; it can be audio input or audio output, depending on if TCVR is in Encoder or Decoder mode respectively |
| IR | (1) 3.5mm IR OUT Port (1) 3.5mm IR-EYE Port (1) 3.5mm I-Pass Port |
| RS232 | (1) x 3 Pin Terminal Block for MXNet System Control |
| USB | (1) USB Type-C for MXNet Service (1) USB Type-B full speed USB 2.0 480 Mbps Data Rate (2) USB Type-A full speed USB 2.0 480 Mbps Data Rate |
| Ethernet Distance | 330 FT over CAT6a |
| SFP+ and Fiber Distance | 10G SFP+ AOC cable up to 3 meters, 10G SFP+ Multimode transceiver over multimode fiber up to 550 meters, 10G SFP+ Single mode transceiver over Single mode fiber up to 20 Kilometers |
| PoE (Power over Ethernet) | IEEE 802.3af (15.4W) |
| Power Supply Unit | Input-AC 120-240V, 50/60Hz, 0.8A / Output-DC 12V, 2A |
