| Signal Type | DVI 1.0, HDMI 2.0b |
| Video Resolution | 4K @ 60Hz 4:4:4, 4K @ 30 Hz 4:4:4, 4K @ 60 Hz 4:2:0 |
| HDR Format | HDR 10, HLG, DV |
| Chroma Subsampling | 444, 422, 420 |
| Bit Depth Per Color | 1080p (16 Bit), 4K (10, 12 Bit) |
| Audio Format | PCM 2, 5.1, 7.1 Channel, Dolby Digital 5.1 Channel, Dolby Digital Plus, DTS 5.1 Channel, DTS-ES, DTS-HD High Resolution |
| Embedded Audio | Stereo Analog Audio |
| De-Embedded Audio | Balanced Analog Audio |
| Ethernet | (1) 10G female RJ45 port for SDVoE transmissions, (1) 1G female RJ45 port for ethernet extension or CBOX control, both are PoE compatible |
| SFP | (1) 10G SFP+ Port used for SDVoE transmissions |
| HDMI | (1) HDMI input (1) HDMI output |
| Audio | (1) TOSLINK, (1) x 3 Pin Terminal Block, (1) 3.5mm female stereo jack, can be audio input or audio output, depending on if TCVR is in encoder or decoder mode respectively |
| IR | (3) x 3.5mm mini-stereo jack, one IR-Pass, one IR-EYE, one IR-out |
| RS232 | (1) x 3 Pin terminal block for MXNet system control |
| USB | (1) USB Type-C for MXNet service, (1) USB Type-B, (2) USB Type-A |
| Ethernet Distance | 330 FT over CAT5E and above |
| SFP+ and Fiber | 10G SFP+ AOC Cable up to 3 meters, 10G SFP+ multimode transceiver over multimode fiber up to 550 meters, 10G SFP+ single mode transceiver over single mode fiber up to 20 kilometers |
| Max Power Consumption | Encoder 11.5W, Decoder 9.816W |
| PoE (Power over Ethernet) | IEEE 802.3af (15.4W) |
| Power Supply Unit | Input-AC 120-240V, 50/60Hz, 0.8A / Output-DC 12V, 2A |
| Thermal Dissipation | Encoder 39.32 BTU/hr, Decoder 33.56 BTU/hr |
