| Signal Type | DVI 1.0, HDMI 2.0b |
| Video Resolution | 4K @ 60Hz 4:4:4, 4K @ 30Hz 4:4:4, 4K @ 60Hz 4:2:0 |
| HDR Format | HDR 10, HLG, DV |
| Chroma Subsampling | 444, 422, 420 |
| Bit Depth per Color | 1080p (16 Bit), 4K (10, 12 Bit) |
| Audio Format | PCM 2, 5.1, 7.1 Channel, Dolby Digital 5.1 Channel, Dolby Digital Plus, DTS 5.1 Channel, DTS-ES, DTS-HD High Resolution |
| Embedded Audio | Stereo Analog Audio |
| De-Embedded Audio | Balanced Analog Audio |
| Ethernet | (6) 10/100/1000 base-T, half/full duplex (auto detect), RJ-45 female ports (port 6 is a POE port) for MXNet System Control and third-party control |
| SFP+ | (1) 10G SFP+ port used for MXNet SDVoE streams and input preview |
| RS232 | (1) x 3 Pin Terminal Block for MXNet System Control |
| USB | (1) USB Type-C for MXNet Service |
| Ethernet Distance | 330 FT over CAT5e |
| SFP+ and Fiber Distance | 10G SFP+ DAC Cable up to 1 meters, 10G SFP+ AOC Cable up to 3 meters, 10G SFP+ Multimode transceiver over Multimode fiber up to 550 meters 10G SFP+ Single mode transceiver over Single mode fiber up to 20 Kilometers |
| OLED Displays | (2) one for CBOx status and one for SDVoE information |
| OLED Display Size | 23mm x 6mm |
| OLED Display Resolution | 128 x 32 pixels |
| Power Consumption | 8.1 W |
| PoE (Power over Ethernet) | IEEE 802.3af (15.4W) |
| Power Supply Unit | Input-AC 120-240V, 50/60 Hz, 0.8A / Output-DC 12V, 2A |
| Thermal Dissipation | 27.7 BTU/hr |
