| Inputs | 4 Stereo Local Inputs, 1 Stereo Bus Input, 1 Digital/Analog Bus Combo Input |
| Input Sensitivity | 1 Vrms for full output, level at maximum |
| Input Gain | 30 dB |
| Amplifier Channels | 8 |
| Power Output (8Ω) | 100W per channel |
| Power Output (4Ω) | 200W per channel |
| Power Output (8Ω Bridged Mono) | 400W |
| Minimum Speaker Load | 4Ω |
| Preamp Audio Outputs | 4 Stereo Local Loop Outputs, 1 Stereo Bus Loop Output |
| Signal to Noise | >97 dB, A-wtd, ref full output |
| Crosstalk | > 80 dB @ 1 kHz |
| Damping Factor | >300 |
| Remote Power Trigger | +12 VDC or Dry Contact Closure |
| Network Connection/Protocol | 10BaseT Ethernet TCP/IP |
| Communication Protocol | HTTP or Telnet |
