| Main input voltage |
120 V AC 1 phase |
| Other input voltage |
110 V
125 V |
| Input connection |
NEMA L5-30P |
| Efficiency at full load |
75...154 V adjustable
82...144 V |
| Input frequency |
50/60 Hz +/- 3 Hz auto-sensing |
| Output voltage |
120 V AC 1 phase |
| Other output voltage |
110 V
125 V |
| Rated power in W |
2700 W |
| Rated power in VA |
2880 VA |
| Output connection |
6 NEMA 5-15R
2 NEMA 5-20R |
| Harmonic distortion |
Less than 5% |
| Maximum configurable power in VA |
2880 VA |
| Maximum configurable power in W |
2700 W |
| Transfer time |
6ms typical : 10ms maximum |
| UPS topology |
Line Interactive |
| Waveform type |
Sine wave |
| Output frequency |
50/60 Hz +/- 3 Hz sync to mains |
| Battery type |
Lead-acid internal battery |
| Battery life |
3…5 year(s) |
| Battery charging power |
172 W rated |
| Control panel |
Multi-function LCD status and control console
LED status display with on line : on battery : replace battery and overload indicators |
| Free slot |
1 |
| Alarm |
Alarm when on battery : distinctive low battery alarm : overload continuous tone alarm |
| UPS connectivity |
Serial port
USB port
SmartConnect port
Available expansion slot |
| Communication port support |
SmartConnect Ethernet port: for cloud monitoring feature availability varies by terms of use |
| Software package |
SmartConnect software for remote power monitoring feature availability varies by terms of use |
| Surge energy rating |
459 J |
| Number of rack unit |
2U |
