| Amplifiers |
Nine Class-D digital amplifiers tuned to the soundbar’s acoustic architecture. |
| Tweeters |
Five tweeters faithfully reproduce high and mid-range frequencies.
The forward-firing mid tweeter provides a smooth center image.
Two side-firing horn-loaded mid tweeters create stereo separation.
Two upward-firing tweeters loaded into a directional horn support spatial audio with Dolby Atmos. |
| Woofers |
Four low-profile woofers deliver powerful bass. |
| Microphones |
Far-field microphone array uses beamforming and multichannel echo cancellation for voice control, Trueplay tuning, and connecting Sonos Play or Move 2 surrounds. Toggle off the mic switch to disconnect. |
| Adjustable EQ |
Use the Sonos app to adjust bass, treble, and loudness. |
| Trueplay |
Measures the acoustics of the room and fine-tunes the EQ. Compatible with iOS and Android devices. |
| AI Speech Enhancement |
AI detects human voices to improve dialogue clarity. Choose from four levels of Speech Enhancement in the Sonos app. |
| Night Sound |
Reduces the intensity of loud sounds and enhances quieter sounds. Enable in the Sonos app. |
| Home Theater Audio Formats |
Dolby Atmos,* Dolby Atmos via Dolby Digital Plus, Stereo PCM, Dolby Digital, Dolby Digital Plus, Dolby TrueHD,* Dolby Atmos via Dolby TrueHD,* Multichannel PCM,* Dolby Multichannel PCM* and DTS Digital Surround.
*HDMI eARC connection required. |
| Dolby Atmos Music |
Dedicated upward-firing drivers support Dolby Atmos Music for spatial audio playback. |
| TV Audio Swap |
Swap TV audio between the soundbar and Sonos headphones. |
| Simulated Overhead Sound |
Optimizes overhead sound effects for when the top of the product is obstructed. Select your setup in the Sonos app. |
| Finish |
Matte |
| LED |
Lights on the product indicate connection, microphone activity, and mute status. |
| Controls |
Touch: Use the capacitive touch controls to play, pause, skip, replay, adjust the volume, turn off voice assistant, and group or ungroup Sonos products
Bluetooth Button: Press to pair a Bluetooth device.
Mic Switch: Toggle off the switch on the back of the product to disconnect power to the microphones. |
| WiFi |
Compatible with WiFi 6. Connect to WiFi with any 802.11a/b/g/n/ac/ax 2.4 GHz/5 GHz broadcast-capable router. |
| HDMI eARC |
Connect to your TV's HDMI eARC/ARC port with the included HDMI cable. Optical adapter sold separately. |
| Bluetooth |
Bluetooth 5.3 supports audio streaming from any Bluetooth-enabled device. |
| Voltage |
100-240V 50/60Hz internal power supply |
| CPU |
Quad Core
4xA55 1.9 GHz |
| Voice |
Works with Sonos Voice Control. |
| Apple AirPlay 2 |
Works with AirPlay 2 on Apple devices iOS 11.4 and higher. |
| USB-C |
Connect an audio source using a 3.5 mm auxiliary cable and the Sonos Line-In Adapter. Connect your router with an ethernet cable and the Sonos Combo Adapter. All accessories sold separately. |
| TV Compatibility |
Not compatible with CCFL-backlit TVs (manufactured 2004-2012) |
| Mounting |
M5 x 0.8mm thread pitch L6.5mm |
